Drilled Titanium Clad Copper Flat Bar

Drilled Titanium Clad Copper Flat Baris a precision machined composite flat bar combining a high conductivity copper core with a corrosion resistant titanium outer layer. Drilled holes can be incorporated into the flat bar according to specific mounting, connection, or equipment requirements.

The flat bar design provides a larger contact surface and convenient installation, while the titanium cladding protects the copper core in demanding operating environments.

Ti-Cu Clad Flat Bar with Holes is a composite material made by bonding pure titanium (Grade 1 or Grade 2) and high conductivity copper (C11000/C10200) through explosive welding or hot rolling. On this clad bar, precision drilling or CNC machining is applied to create straight holes, deep holes, countersunk holes, or custom hole patterns, enabling direct installation in electrochemical equipment and power distribution systems.

We manufacture custom drilled titanium clad copper flat bars according to customer drawings, samples, or technical specifications. Bar width, thickness, length, titanium cladding thickness, hole diameter, hole spacing, and hole layout can all be customized.

Key Features

      · Copper core for efficient electrical conduction

      · Titanium cladding for corrosion resistance

      · Flat bar geometry for convenient installation and connection

      · Precision drilled holes based on customer drawings

      · Custom hole diameter, quantity, spacing, and position

      · Custom titanium cladding thickness

      · Machined edges and surfaces available

      · Suitable for electrochemical and industrial applications

      · OEM and drawing-based manufacturing

Strong Metallurgical Bonding

Titanium is bonded to copper through explosive welding / hot rolling, forming high-strength, high-conductivity composite material.

Customized Drilling & CNC Machining

We provide:

· Through hole drilling

· Deep drilling

· Countersunk holes

· Slot holes

· Threaded holes

· Multi-hole patterns for electrical installation

Accuracy:±0.05 mm-±0.1 mm.

Excellent Corrosion Resistance + High Conductivity

Titanium (Ti) layer protects against acid, alkali, chlorine, seawater, electrolysis environments

Copper ensures excellent electrical and thermal conductivity

Lightweight + Cost Effective

A Ti-Cu clad bar offers titanium corrosion resistance at 1/3 the cost of solid titanium bars.

The drilled design allows the flat bar to be supplied as a finished component rather than requiring additional hole machining after delivery.

Depending on the drawing, we can manufacture:

· Through holes

· Blind holes

· Threaded holes

· Counterbored holes

· Countersunk holes

· Single holes

· Multiple-hole patterns

· Regular or irregular hole layouts

Hole diameter, center distance, edge distance, depth, and positional tolerances can be controlled according to the customer's specifications.

For projects using the term Titanium Clad Copper Perforated Bar, we can also manufacture perforated or multi-hole configurations based on the required layout.

A typical production route includes:

Copper & Titanium Preparation → Surface Preparation → Cladding/Bonding → Sizing → Cutting → Flat Bar Machining → Drilling → Edge & Surface Finishing → Inspection → Packaging

The actual manufacturing process is selected according to the composite structure, dimensions, cladding requirements, hole configuration, and specified tolerances.

1. Raw Material Selection & Surface Cleaning

Titanium plates / bars and electrolytic copper

Surface degreasing, brushing, descaling

2. Explosive Welding or Hot Rolling Compound

Titanium and copper bonded under high-energy explosive welding

Or composite hot rolling

Achieves metallurgical bonding

3. Hot Rolling / Cold Rolling / Straightening

· Adjust thickness     · Improve bonding uniformity      · Ensure good flatness

4. Annealing / Heat Treatment

· Relieve stress      · Stabilize structure      · Improve machinability

5. Precision Machining

· Sawing     · Milling     · Grinding     · Surface shaving

6. CNC Drilling Process

Our drilling capabilities:

· Vertical CNC drilling    · Multi-axis machining center    · Deep hole drilling machines    · Automated drilling with positioning fixtures

Hole types:

· Straight hole / deep hole    · Blind hole    · Threaded hole    · Countersunk hole    · Slot hole    · Multi-row hole grid

Accuracy:

Straightness ≤ 0.05 mm

Surface roughness Ra 1.6-3.2

7. Final Inspection

· Ultrasonic testing (UT)    · Eddy current testing (ET)    · Bonding strength test    · Dimensional check    · Surface inspection

8. Packaging

Poly bag + foam + export wooden case, Protection for long-distance marine transport

Drilled titanium clad copper flat bars are suitable for equipment and assemblies where electrical conductivity, corrosion resistance, and precise installation features are required.

Typical applications include:

· Electroplating equipment

· Electrolysis systems

· Electrochemical equipment

· Industrial electrodes

· Current-carrying components

· Conductive connections

· Chemical processing equipment

· Corrosion-resistant electrical assemblies

· Electrochemical fixtures

· Customized industrial equipment

· Electrolytic copper refinery

· Chlor-alkali plant

· PCB manufacturing

· Power distribution system

· Cathodic protection

· Marine engineering

· Water treatment systems

· Hydrogen production electrolyzers

The appropriate titanium grade, copper grade, cladding thickness, and hole design depend on the operating current, chemical environment, temperature, mechanical loads, and installation conditions.

Specific uses：

· Titanium clad copper busbar

· Anode/cathode clamps

· Electrical connection plates

· Conductive support plates

· Electrolyzer cell busbars

· Electrode holders

Get a Customized Quote

Provide your requirements:

· Size (thickness × width × length)

· Titanium/copper grade

· Hole diameter, position, drawing or sketch

· Quantity

· Surface requirements

A titanium clad copper flat bar is designed to combine the advantages of two materials in one component.

Copper core provides high electrical conductivity.

Titanium cladding provides a corrosion-resistant working surface.

Flat-bar geometry offers a broad contact area and convenient mounting.

Precision drilling allows holes and connection features to be integrated into the finished component.

This composite design can be advantageous where a conventional copper flat bar may have insufficient corrosion resistance and solid titanium may not provide the required electrical conductivity.

Need a Drilled Titanium Clad Copper Flat Bar manufactured to your drawing?

Send us your flat bar dimensions, hole layout, titanium/copper grades, cladding thickness, quantity, and application. Our team can review the requirements and provide a customized quotation.
